Incoloy Alloy 800/800H/800HT Sheets & Plates Plain End|Incoloy Alloy 800/800H/800HT Sheets & Plates Bevelled End|Incoloy Alloy 800/800H/800HT Sheets & Plates Threaded Stockist|Incoloy Alloy 800 N08800|Incoloy Alloy 800/800H/800HT Sheets & Plates Supplier In India.
ASTM B 409 Incoloy Alloy 800/800H/800HT Sheets & Plates Exporter| Incoloy Alloy 800/800H/800HT Sheets & Plates|Incoloy Alloy 800/800H/800HT Plates|Incoloy Alloy 800/800H/800HT Sheets|Incoloy Alloy 800/800H/800HT Sheets & Plates Exporter In India.
Apple Metals we are leading supplier,exporter and trader, we offers our clients a wide range of Incoloy 800 Sheets in India. Power plants use them for super-heater and re-heater tubing. Incoloy 800 Plates (UNS N08800) is also used for process piping, heat exchangers, heating-element sheathing, carburizing equipment, and nuclear steam-generator tubing. Alloy 800 Sheets hardens due to cold working only. It has improved creep and stress-rupture characteristics in the 1100 Degree F (593 Degree C) to 1800 Degree F (982 Degree C) temperature range. Alloy 800 Plates are resistant to chloride ion stress corrosion cracking. Nickel 800 Sheets are also used for chemical and petrochemical processing. Nickel 800 Plates can be supplied in random lengths, cut to order or machined to customer requirements. We also offer the same to our clients in customized sizes and specifications.
Alloy 800 Sheets (UNS N08800 Sheets) is a broadly utilized material of development for hardware that must have high quality and oppose carburization, oxidation and other hurtful impacts of high-temperature presentation. In the mean time, for high temperature applications requiring ideal break and crawl properties, Alloy 800H Plates (UNS N08810 Plates) and Alloy 800HT Coils (UNS N08811 Coils) are utilized.
We offer these Inconel Alloy 800, 800H, 800HT Sheets Plates in uniquely designed shapes and sizes according to the prerequisites given by our customers, and that too at a moderate and market driving costs.
SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800 HT SHEETS PLATES :
| Standards : | ASTM B 409/ ASME SB 409 |
| Grades : | Incoloy 800 Sheets – UNS N08800, Incoloy 800H / HT Plates – UNS N08810 |
| Type : | Sheet, Plates, Flat |
| Length : | Single Random, Double Random & Cut Length |
| End : | Plain End, Bevelled End, Threaded |
| Range : | 0.3mm to 150mm |
| Hardness : | Hardness: Soft, Hard, Half Hard, Spring Hard, etc. |
| Finish : | Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
| Form: | Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
| Other services : | Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. |
GRADE SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800 HT SHEETS PLATES :
| Inconel Alloy | Tradename | UNS no. | Werkstoff No. |
| 800 | Incoloy Alloy 800 | N08800 | 1.4876 |
| 800H | Incoloy Alloy 800H | N08810 | 1.4876 |
| 800HT | Incoloy Alloy 800HT | N08811 | 1.4876 |
CHEMICAL COMPOSITION OF INCOLOY ALLOY 800/800H/800 HT SHEETS PLATES :
|
Alloy |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.1 max |
1.5 max |
.015 max |
1.0 max |
|
|
Alloy 800H |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.05-.10 max |
1.5 max |
.015 max |
1.0 max |
|
|
Alloy 800HT |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.25-.60 |
.85-1.20 |
.06-.10 max |
1.5 max |
.015 max |
1.0 max |
MECHANICAL PROPERTIES OF INCOLOY ALLOY 800/800H/800 HT SHEETS PLATES :
|
|
INCOLOY 800 |
INCOLOY 800H |
INCOLOY 800HT |
|
Density |
7.94 g/cm3 |
7.94 g/cm3 |
7.94 g/cm3 |
|
Melting Range,℃ |
1350-1400 ℃ |
1350-1400 ℃ |
1350-1400 ℃ |
|
Elongation % |
30-35 |
30-35 |
30-35 |
|
Tensile strength – Mpa |
500 |
500 |
500 |
|
Yield strength – Mpa |
205 |
200 |
200 |
