Apple Metalswe are the manufacturer and supplier of Incoloy Alloy 800/800H/800HT Flanges. These Flanges are At the point when presented to high-temperature these combinations give great resistance to oxidation as well as great quality as well. Incoloy Alloy 800 Flanges (UNS N08800 Flanges), Incoloy Alloy 800H Flanges (UNS N08810 Flanges) and Incoloy Alloy 800HT Flanges (UNS N08811 Flanges) are often used in home appliances for sheathing of electric heating elements. In the production of paper pulp, digester liquid heaters are often made of Incoloy Alloy 800. In petroleum processing, these WNR 1.4876 Flanges, WNR 1.4958 Flanges and WNR 1.4859 Flanges are used for heat exchangers that air-cool the process stream..
These Incoloy 800/H/HT Flanges are all around attempted on various parameters to meet the mass essentials of our regarded clients. Furthermore, these can moreover be uniquely created by given purposes of enthusiasm of clients. We offer these Incoloy Flanges to clients in settled squeezing's at moderate rates.
SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800HT FLANGES :
| Grades : | Inconel 800H/HT |
| Dimensions : | ANSI B 16.5, BS 1560. BS 10, IS 6392, B-2.1 NPT, API, DIN, JIS. MSS SP 44 |
| Standards : | ASTM / ASME SB 564 / 160 / 472 |
| Size : | 1/2″NB TO 12″NB |
| Class : | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS , ASA 150#, ASA 300# DIN ND 6,10,16,25,40 Etc. |
| Flange Face Type : | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
GRADE SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800HT FLANGES :
| Inconel Alloy | Tradename | UNS no. | Werkstoff No. |
| 800 | Incoloy Alloy 800 | N08800 | 1.4876 |
| 800H | Incoloy Alloy 800H | N08810 | 1.4876 |
| 800HT | Incoloy Alloy 800HT | N08811 | 1.4876 |
CHEMICAL COMPOSITION OF INCOLOY ALLOY 800/800H/800HT FLANGES :
|
Alloy |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.1 max |
1.5 max |
.015 max |
1.0 max |
|
|
Alloy 800H |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.05-.10 max |
1.5 max |
.015 max |
1.0 max |
|
|
Alloy 800HT |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.25-.60 |
.85-1.20 |
.06-.10 max |
1.5 max |
.015 max |
1.0 max |
MECHANICAL PROPERTIES OF INCOLOY ALLOY 800/800H/800HT FLANGES :
|
|
INCOLOY 800 |
INCOLOY 800H |
INCOLOY 800HT |
|
Density |
7.94 g/cm3 |
7.94 g/cm3 |
7.94 g/cm3 |
|
Melting Range,℃ |
1350-1400 ℃ |
1350-1400 ℃ |
1350-1400 ℃ |
|
Elongation % |
30-35 |
30-35 |
30-35 |
|
Tensile strength – Mpa |
500 |
500 |
500 |
|
Yield strength – Mpa |
205 |
200 |
200 |
