Apple Metals is one of the prime manufacturers of Incoloy 800 / 800H / 800HT / 825 Pipes and Tubes that are being sourced by using high quality of raw material and makes sure to provide durability of highest quality of industry standard products. Incoloy 800 Pipes (Alloy 800), Incoloy 800H Pipes (Alloy 800H) and Incoloy 800HT Pipes (Alloy 800HT) are nickel-iron-chromium alloys by means of having excellent strength and good resistance to oxidation, along with having carburization in soaring-temperature exposure. However, Incoloy 825 Pipes (Alloy 825) is a nickel-iron-chromium alloy by means of having additions of copper and molybdenum. Also referred as UNS N08800, UNS N08810, UNS N08811 and UNS N08825, these pipes and tubes respectively can further be customized in terms of sizes and thicknesses as per specific requirements given by our esteemed clients. And also referred as WNR 1.4876, WNR 1.4958, WNR 1.4859 and 2.4858, we offer the same at market leading prices..
Applications of Alloy 800 Pipes and Tubes (UNS N08800 Capillary tubes), Alloy 800H Capillary tubes (UNS N08810 Capillary tubes) and Alloy 800HT Capillary tubes (UNS N08811 Capillary tubes) have reached out from petrochemical handling reformer tubing, to howls and flare tips in refinery administration.
We offer these Inconel Alloy 800, 800H, 800HT Products in uniquely crafted shapes and sizes according to the prerequisites given by our customers, and that too at a moderate and market driving costs.
SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800HT CAPILLARY TUBES :
| Outer Diameter : | 0.28mm -10mm |
| Grades : | Inconel 800/H/HT |
| Standard : | ASTM, ASME and API |
| Wall Thickness : | 0.08mm - 1.2mm |
| Size : | 1/8" NB to 60" NB & 1mm OD to 1500mm OD |
| Thickness: | 0.3mm to 100mm, SCH 5, SCH 10, SCH 20, SCH 40, SCH 80, SCH 160, SCH XXS, SCH XS. | Types : | Seamless, Welded, ERW, Boiler tubes, Capillary, Fabricated, Corrugated, Conduit & Large Diameter Pipes. |
| Form : | Round pipes/tubes, Square pipes/tubes, Rectangle pipes/tubes, Coiled tubes, Hydraulic tubes, Ep pipes/ tubes, etc. |
| End : | Plain end, Beveled end, Threaded end & Conduit |
| Length : | Single Random, Double Random & Cut Length |
GRADE SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800HT CAPILLARY TUBES :
| Inconel Alloy | Tradename | UNS no. | Werkstoff No. |
| 800 | Incoloy Alloy 800 | N08800 | 1.4876 |
| 800H | Incoloy Alloy 800H | N08810 | 1.4876 |
| 800HT | Incoloy Alloy 800HT | N08811 | 1.4876 |
CHEMICAL COMPOSITION OF INCOLOY ALLOY 800/800H/800HT CAPILLARY TUBES :
Alloy |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.1 max |
1.5 max |
.015 max |
1.0 max |
|
Alloy 800H |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.05-.10 max |
1.5 max |
.015 max |
1.0 max |
|
Alloy 800HT |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.25-.60 |
.85-1.20 |
.06-.10 max |
1.5 max |
.015 max |
1.0 max |
MECHANICAL PROPERTIES OF INCOLOY ALLOY 800/800H/800HT CAPILLARY TUBES :
|
INCOLOY 800 |
INCOLOY 800H |
INCOLOY 800HT |
Density |
7.94 g/cm3 |
7.94 g/cm3 |
7.94 g/cm3 |
Melting Range,℃ |
1350-1400 ℃ |
1350-1400 ℃ |
1350-1400 ℃ |
Elongation % |
30-35 |
30-35 |
30-35 |
Tensile strength – Mpa |
500 |
500 |
500 |
Yield strength – Mpa |
205 |
200 |
200 |
