Incoloy Alloy 800 N08800|Incoloy Alloy 800H N08810|Incoloy Alloy 800HT N08811|Incoloy Alloy 800/800H/800HT Hot rolled plate Coils & Strips|Incoloy Alloy 800/800H/800HT Cold rolled sheet Coils & Strips Stockist|Incoloy Alloy 800/800H/800HT Coils & Strips Supplier In Mumbai.
ASTM A 168 Incoloy Alloy 800/800H/800HT Coils & Strips|ASME SB 168 Incoloy Alloy 800/800H/800HT Coils & Strips Exporter| Incoloy Alloy 800/800H/800HT Coils & Strips|Incoloy Alloy 800/800H/800HT Strips Exporter In India|Incoloy Alloy 800H Coils & Strips|Incoloy Alloy 800HT Coils & Strips|Incoloy Alloy 800 Coils & Strips.
Apple Metals Apple Metals is one of the fundamental Supplier,Stockist and Exporter of Inconel 800, 800H, 800HT coils-strips Incoloy 800 is a nickel-chromium alloy with high strength and superb resistance & Incoloy 800H and 800 HT are nickel-iron-chromium alloys. We are a leading supplier and exporter of Incoloy 800/800H/800HT Strips& Coils. We provide Incoloy Alloy 800/800H/800HT Strips & Coils globally as per made to order requirements given by our highly valued clients, to meet the quality demands of our customers..
Incoloy alloy 800/H/HT is broadly utilized for development of gear requiring erosion resistance, heat resistance, quality, and dependability for administration up to 1500°F (816°C). Alloy 800/H/HT offers general erosion imperviousness to numerous fluid media and opposes stress consumption breaking. Incoloy 800H has lower carbon content and higher crawl and break resistance. Incoloy 800/800H/HT has further changes to the consolidated titanium and aluminum levels (0.85-1.20%) to guarantee ideal high temperature properties.
SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800 HT COILS & STRIPS :
Standard : |
AISI, ASTM, DIN, JIS, GB, BS |
Thickness : |
0.3mm~15mm |
Specifications : |
ASTM / ASME SB 168, ASTM / ASME SB 424 , ASTM / ASME SB 443 |
Width : |
3.5mm~2000mm |
Grade : |
Incoloy Alloy 800/800H/800HT Coils & Strips |
Range: |
0.3mm to 150mm |
Form: |
Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
Hardness: |
Soft, Hard, Half Hard, Spring Hard, etc. |
Finish: |
Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
Other services: |
Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. |
GRADE SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800HT COILS & STRIPS :
| Inconel Alloy | Tradename | UNS no. | Werkstoff No. |
| 800 | Incoloy Alloy 800 | N08800 | 1.4876 |
| 800H | Incoloy Alloy 800H | N08810 | 1.4876 |
| 800HT | Incoloy Alloy 800HT | N08811 | 1.4876 |
CHEMICAL COMPOSITION OF INCOLOY ALLOY 800/800H/800HT COILS & STRIPS :
|
Alloy |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.1 max |
1.5 max |
.015 max |
1.0 max |
|
|
Alloy 800H |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.05-.10 max |
1.5 max |
.015 max |
1.0 max |
|
|
Alloy 800HT |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.25-.60 |
.85-1.20 |
.06-.10 max |
1.5 max |
.015 max |
1.0 max |
MECHANICAL PROPERTIES OF INCOLOY ALLOY 800/800H/800HT COILS & STRIPS :
|
|
INCOLOY 800 |
INCOLOY 800H |
INCOLOY 800HT |
|
Density |
7.94 g/cm3 |
7.94 g/cm3 |
7.94 g/cm3 |
|
Melting Range,℃ |
1350-1400 ℃ |
1350-1400 ℃ |
1350-1400 ℃ |
|
Elongation % |
30-35 |
30-35 |
30-35 |
|
Tensile strength – Mpa |
500 |
500 |
500 |
|
Yield strength – Mpa |
205 |
200 |
200 |
Apple Metals Supplies Incoloy Alloy 800/800H/800HT Coils & Strips in Agartala, Agra, Agra Rampur, Ahmedabad, Aizawl, Ajmer, Aligarh, Allahabad, Alwar, Amaravati, Ambala, Ambattur, Ambernath, Amravati, Amritsar, Aurangabad, Bangalore, Bareilly, Belgaum, Bhagalpur, Bhavnagar, Bhilai, Bhiwandi, Bhopal, Bhubaneswar, Bidhannagar, Biharsharif, Bikaner, Bilaspur, Bokaro, Chandigarh, Chennai, Chittoor, Coimbatore, Cuttack, Dahod, Davanegere, Dehradun, Delhi, Dhanbad, Dharamsala, Dindigul, Diu, Durgapur, Erode, Faridabad, Fatehpur, Gandhidham, Gandhinagar, Ghaziabad, Greater Hyderabad, Greater Mumbai, Greater Warangal, Gurgaon, Guwahati, Gwalior, Haldia, Howrah, Hubballi-Dharwad, Hyderabad, Imphal, Indore, Jabalpur, Jaipur, Jalandhar, Jammu, Jamnagar, Jamshedpur, Jhansi, Jodhpur, Junagadh, Kakinada, Kalyan-Dombivali, Kanpur, Karnal, Kavaratti, Kochi, Kohima, Kolhapur, Kolkata, Kota, Lucknow, Ludhiana, Madurai, Mehsana, Mangalore, Mangaluru, Mira-Bhayandar, Moradabad, Morbi, Mumbai, Muzaffarpur, Mysore, Nagpur, Namchi, Nasik, Navi Mumbai, NDMC, Nellore, New Delhi, New Town Kolkata, Noida, Oulgaret, Pali, Panaji, Panipat, Panvel, Pasighat, Patiala, Patna, Pimpri-Chinchwad, Port Blair, Puducherry, Pune, Raipur, Rajkot, Ranchi, Raurkela, Industrial Township, Rourkela, Sagar, Salem, Satna, Secunderabad, Shaharanpur, Shillong, Siliguri, Silvassa, Solapur, Srinagar, Surat, Thane, Thanjavur, Thiruvananthapuram, Thoothukudi, Thrissur, Tiruchirapalli, Tirunelveli, Tirupur, Tumkur, Udaipur, Ujjain, Ulhasnagar, Vadodara, Vapi, Varanasi, Vasai-Virar, Vellore, Vishakhapatnam.
Apple Metals exports Incoloy Alloy 800/800H/800HT Coils & Strips to Countries like India, United States, United Arab Emirates, Canada, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Saudi Arabia, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Angola, Argentina, Austria, Azerbaijan, Bangladesh, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia.
For further enquiries related to INCOLOY ALLOY 800/800H/800 HT COILS & STRIPS kindly get back to us on :- applemetals@gmail.com or contact us on +91 9821406604 / +91 9821406604
