Apple Metals we are Supplier and Exporter of Super Duplex Steel Ferralium 255 SD50 Sheets & Plates In India, Mumbai. we produce our materials using high quality raw materials for high resistance of our product. we also provide various grades ASTM A479/ A276/ A473, A182/A240 UNS S32550, F61, UNS S32520, UNS S39553. we have various finishes such as Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated). we also take on clients requests as per their specifications.
Duplex 255 is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel expected for asking for applications which require incredible quality and utilization resistance, for instance, substance technique, petrochemical, and seawater equipment. Gathering of mechanical duplex stainless steel and super duplex steel offered by us is fabricated in sound foundation encouraged with cutting edge and propelled machines. We make sure that the Ferralium 255 SD50 (UNS-S32550) Super Duplex Steel Sheets and Plates goes through various level of quality testing before it is delivered to our client.
SPECIFICATION :
| Standards | ASTM A479/ A276/ A473, A182/A240 UNS S32550, F61, UNS S32520, UNS S39553 |
|---|---|
| Dimensions | ASTM, ASME and API |
| Range : | 0.3mm to 150mm |
| Hardness : | Hardness: Soft, Hard, Half Hard, Spring Hard, etc. |
| Finish : | Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
| Form: | Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
| Other services : | Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. |
| Application | Chemical Process Industry: Sulphuric Acid Production, Nitric Acid Processes, Polypropylene Production, PVC ProductionTitanium Dioxide Production, Caustic Evaporators, Equipment Handling Organic and Fatty Acids Marine Industry and Shipbuilding: Propellers and Shafts, Rudders, Shaft Seals, Pumps, Bolts and Fasteners, Valves, Instrumentation, Oil and Chemical Tankers Oil and Gas Industry: Pumps, Valves, Pipe, Vessels, Wellhead Equipment, Subsea Equipment Pollution Control: Fans and pumps, Wet Scrubbers, Incinerators Copper Smelting: ID Fans, Tuyere bars, Wet Scrubbers, Leaching Area Precipitators Pulp and Paper Industry: Black liquor heater tubes, Digester Blow Valves, Rotary Feed Valves, I.D.Fans, Brownstock Washers, Precipitators, Bleaching Components Food Industry: Sugar Cane Centrifuges, Corn and Vegetable processing plant Agrochemicals: Fertilizer Production (Wet phosphoric acid) Civil Engineering: Statue of Liberty supporting structure, Swimming Pools, Sewage Treatment |
GRADE SPECIFICATION :
| Super Duplex Steel | Tradename | UNS no. | Werkstoff No. |
| 4507 | FERRALIUM 255-SD50 | S32550 | 1.4507 |
CHEMICAL COMPOSITION :
| C | Cr | Cu | Fe | Mo | Mn | N | Ni | P | S | Si | |
| Minimum | 24.0 | 1.50 | REMAINDER | 2.90 | 0.10 | 4.50 | |||||
| Maximum | 0.040 | 27.00 | 2.50 | 3.90 | 1.50 | 0.25 | 6.50 | 0.040 | 0.030 | 1.00 |
MECHANICAL PROPERTIES :
| 0.2% Proof Stress (N/mm2 )[ksi] minimum | 550 [79.8] |
| Ultimate Tensile Strength (N/mm2) [ksi] minimum | 760 [110.3] |
| Elongation (%) minimum | 25 |
| Hardness (HBN) | 270max |
| Charpy V-notch Impact at ambient Temp (J) [ft.lb] | 80min [59min] |
| Charpy V-notch Impact at -46°C (J) [ft.lb] | 45av, 35min [33av, 25.8min] |
PHYSICAL PROPERTIES :
| Density (Kg.m-1) | 78.1 |
| Magnetic Permeability | 33 |
| Young’s Modulus (N/mm2) | 199 x 103 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 475 |
| Fracture Toughness, KQ (MPa.m½) | 98 |
| Specific Electrical Resistance, 20°C (µO.m) | 0.80 |
| Thermal conductivity, 20°C (W.m-1.°K-1) | 14.2 |
| Mean coefficient of thermal expansion, 20-100°C (°K-1) | 11.1 x 10-6 |
