ASME SA240 Stainless Steel 304,304L,304H Coils & Strips ExporterStainless Steel 304,304L,304H Coils & Strips|Stainless Steel 304,304L,304H Coils|Stainless Steel 304,304L,304H Strips|Stainless Steel 304,304L,304H Coils & Strips Exporter In India|ASTM A240 Stainless Steel 304,304L,304H Coils & Strips.
304L Stainless S30403|1.4307 Stainless Steel 304,304L,304H Coils & Strips| 304H SS S30409|1.4948 SS 304,304L,304H Coils & Strips Stockist . SS 304,304L,304H Foils|SS 304,304L,304H Rolls|304 SS S30400|1.4301 SS 304,304L,304H Coils & Strips.
Apple Metalswe are Supplier and Exporter of Stainless Steel 304,304L,304H Coils & Strips In India, Mumbai. we produce our materials using high quality raw materials for high resistance of our product. we also provide various grades ASTM A240 / ASME SA240. we also take on clients requests as per their specifications.
Stainless Steel 304,304L,304H Coils & Strips are widely acknowledged for the best quality, corrosion, abrasion and high tensile strength with long life service. Stainless Steel 304,304L,304H Coils & Strips are widely used in chemical, textile, petroleum and food industry, marine and industrial exposure.
We offer qualitative scope of these Stainless Steel 304/304L/304H Coils & Strips in various sizes and shapes that are designed as per the national and worldwide standard nature of raw materials. These Stainless Steel 304, 304L, 304H Coils & Strips are fabricated and tested by the technical experts to meet the requirements of the clients.
SPECIFICATIONS OF STAINLESS STEEL 304,304L, 304H COILS & STRIPS :
| Standard : | ASTM A240 / ASME SA240 |
| Grade : | SS 304 , SS 304L , SS 304H |
| Thickness : | 4.0mm - 100mm |
| Length : | 3000mm,6000mm,12000mm |
Range: |
0.3mm to 150mm |
Form: |
Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
Hardness: |
Soft, Hard, Half Hard, Spring Hard, etc. |
Finish: |
Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
Other services: |
Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. |
| Applications : |
|
GRADE SPECIFICATIONS OF STAINLESS STEEL 304,304L, 304H COILS & STRIPS :
| Stainless Steel | Tradename | UNS no. | Werkstoff No. |
| 304 | 304 Stainless | S30400 | 1.4301 |
| 304L | 304L Stainless | S30403 | 1.4307 |
| 304H | 304H Stainless | S30409 | 1.4948 |
CHEMICAL COMPOSITION OF STAINLESS STEEL 304,304L, 304H COILS & STRIPS :
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 304 | min. | - | - | - | - | - | 18.0 | - | 8.0 | - |
| max. | 0.08 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | 0.10 | ||
| 304L | min. | - | - | - | - | - | 18.0 | - | 8.0 | - |
| max. | 0.030 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 12.0 | 0.10 | ||
| 304H | min. | 0.04 | - | - | - | - | 18.0 | - | 8.0 | - |
| max. | 0.10 | 2.0 | 0.75 | 0.045 | 0.030 | 20.0 | 10.5 | - | ||
MECHANICAL PROPERTIES OF STAINLESS STEEL 304,304L, 304H COILS & STRIPS :
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 304 | 515 | 205 | 40 | 92 | 201 |
| 304L | 485 | 170 | 40 | 92 | 201 |
| 304H | 515 | 205 | 40 | 92 | 201 |
PHYSICAL PROPERTIES OF STAINLESS STEEL 304,304L, 304H COILS & STRIPS :
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion (m/m/0C) |
Thermal Conductivity (W/m.K) |
Specific Heat 0-1000C (J/kg.K) |
Electrical Resistivity (n.m) |
|||
0-1000C |
0-3150C |
0-5380C |
at 1000C |
at 5000C |
|||||
304/304L/304H |
8000 |
193 |
17.2 |
17.8 |
18.4 |
16.2 |
21.5 |
500 |
720 |
Apple Metals Supplies Stainless Steel 304,304L,304H Coils & Strips in Agartala, Agra, Agra Rampur, Ahmedabad, Aizawl, Ajmer, Aligarh, Allahabad, Alwar, Amaravati, Ambala, Ambattur, Ambernath, Amravati, Amritsar, Aurangabad, Bangalore, Bareilly, Belgaum, Bhagalpur, Bhavnagar, Bhilai, Bhiwandi, Bhopal, Bhubaneswar, Bidhannagar, Biharsharif, Bikaner, Bilaspur, Bokaro, Chandigarh, Chennai, Chittoor, Coimbatore, Cuttack, Dahod, Davanegere, Dehradun, Delhi, Dhanbad, Dharamsala, Dindigul, Diu, Durgapur, Erode, Faridabad, Fatehpur, Gandhidham, Gandhinagar, Ghaziabad, Greater Hyderabad, Greater Mumbai, Greater Warangal, Gurgaon, Guwahati, Gwalior, Haldia, Howrah, Hubballi-Dharwad, Hyderabad, Imphal, Indore, Jabalpur, Jaipur, Jalandhar, Jammu, Jamnagar, Jamshedpur, Jhansi, Jodhpur, Junagadh, Kakinada, Kalyan-Dombivali, Kanpur, Karnal, Kavaratti, Kochi, Kohima, Kolhapur, Kolkata, Kota, Lucknow, Ludhiana, Madurai, Mehsana, Mangalore, Mangaluru, Mira-Bhayandar, Moradabad, Morbi, Mumbai, Muzaffarpur, Mysore, Nagpur, Namchi, Nasik, Navi Mumbai, NDMC, Nellore, New Delhi, New Town Kolkata, Noida, Oulgaret, Pali, Panaji, Panipat, Panvel, Pasighat, Patiala, Patna, Pimpri-Chinchwad, Port Blair, Puducherry, Pune, Raipur, Rajkot, Ranchi, Raurkela, Industrial Township, Rourkela, Sagar, Salem, Satna, Secunderabad, Shaharanpur, Shillong, Siliguri, Silvassa, Solapur, Srinagar, Surat, Thane, Thanjavur, Thiruvananthapuram, Thoothukudi, Thrissur, Tiruchirapalli, Tirunelveli, Tirupur, Tumkur, Udaipur, Ujjain, Ulhasnagar, Vadodara, Vapi, Varanasi, Vasai-Virar, Vellore, Vishakhapatnam.
Apple Metals exports Stainless Steel 304,304L,304H Coils & Strips to Countries like India, United States, United Arab Emirates, Canada, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Saudi Arabia, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Angola, Argentina, Austria, Azerbaijan, Bangladesh, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia.
For further enquiries related to STAINLESS STEEL 304/304L/304H COILS & STRIPS kindly get back to us on :- applemetals@gmail.com or contact us on +91 9821406604 / +91 9821406604
